1.0KW ISO1600 X Ray Parcels Scanner SA6550 140kv Airport X Ray Machine

    Buy cheap 1.0KW ISO1600 X Ray Parcels Scanner SA6550 140kv Airport X Ray Machine from wholesalers

    Buy cheap 1.0KW ISO1600 X Ray Parcels Scanner SA6550 140kv Airport X Ray Machine from wholesalers
    • Buy cheap 1.0KW ISO1600 X Ray Parcels Scanner SA6550 140kv Airport X Ray Machine from wholesalers
    • Buy cheap 1.0KW ISO1600 X Ray Parcels Scanner SA6550 140kv Airport X Ray Machine from wholesalers

    1.0KW ISO1600 X Ray Parcels Scanner SA6550 140kv Airport X Ray Machine

    Ask Lasest Price
    Brand Name : Securina
    Model Number : SA6550
    Certification : FCC/CE
    Price : $4999 - $29999/set
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 800 Set/Sets per Month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    1.0KW ISO1600 X Ray Parcels Scanner SA6550 140kv Airport X Ray Machine

    Dual Energy Color Scanning Image X-Ray Parcels Scanner SA6550 X Ray Machine At Airport


    With better medical conditions and a safer practice environment, both doctors and patients will be more ‘‘harmonious’’. The effect of the security check-in system in the hospital may not completely prevent the wounded and the doctor from killing the doctor, but at least most of the murder weapons can be blocked outside the hospital. The security check can also greatly deter criminals and shock the criminals’ psychology. Maybe, The criminal motives of some criminals can be eliminated in the bud.


    Recommend solution design:
    1. Establish security checkpoints at the entrances and exits of the hospital, equipped with security inspection x-ray machines, explosive detectors, and dangerous liquid detectors for inspection of report items of personnel entering and leaving the hospital, and equipped with explosion-proof tanks for emergency and temporary disposal of suspected objects.
    2. Equipped with thermal imaging security screening gates or wide-channel security gates (patients pass through), hand-held metal detectors, used to detect whether personnel entering and leaving the hospital carry prohibited metal products, and personnel will ask questions and monitor during the epidemic.
    3. Person card + gate authentication channel, to verify the identity information of personnel entering and exiting, and connect to the public security network system online
    4. The main passages in the hospital and key areas are fully covered by video surveillance, and one-key alarm devices are equipped in key areas such as emergency rooms and security checkpoints.
    5. Establish a green channel for emergency handling.


    SA6550 X Ray Machine Specification:


    Tunnel Size650(W)*500(H)mm
    Conveyor Speed0.22m/s
    Conveyor Max Load170kg
    Dose per Inspection<2.9μ Gy/h
    Resolution<0.101mm Metal Wire
    Spatial resolutionLevel: Dia1.0mm, Vertical: Dia1.3mm
    Penetrate resolutionDia 0.511mm
    Penetration30-32mm steel
    Film SafetyGuarantee ISO1600 Film
    X-ray Leakage<0.5 μ Gy/h (at a distance of 5cm From external housing)
    Image System :
    Technical PrincipleDual-energy X-ray Imaging; L Shaped Array
    X-ray SensorL-Shaped Photodiode Array (multi-energetic)
    MonitorHigh Resolution Color, LCD Accord, 17inch
    Image DisplayHigh resolution of 1024 * 1280 pixel; Image Grey Level: 65536
    Image Enhancement1-64times enlargement continuity, Color/BW, negative, high/low
    penetration, organic /inorganic Stripping, general enhancement, and pseudo color, etc.
    Image Recall:All preceding images recallable, retrieval.
    Explosives & Narcotics DetectionExplosives & narcotics alarm and highlight according to atomic number signature
    High Density Region AlarmImpenetrable region alarm and highlight, for possible concealing of
    threats and contrabands
    Image ArchiveUp to 100,000 images stored automatically, enable transferring to USB disk, and
    converting to JPG, BMP and other general formats
    Miscellaneous FunctionsTime/date display, counters, user management, system-on/X-ray-on
    timers, power on self test, built-in diagnostic facilities, dual-direction scanning, system log, system standby and stimulant training,etc
    Network ApplicationsMultiple remote applications available based on Ethernet LAN and
    windows platform, such as image centralized storage and identify, recheck workstation, and network TIP, etc ( Optional) .
    Images process24bit real time processing ,4colors analysis, Images displayed marked date and ID NO ,Count the number of bags ,Memory gray level:65536
    Operating Environment:
    Operation temperature/Humidity0ºC-40ºC/10%-95%(non-condensing)
    Storage Temperature/Humidity-20ºCto 60ºC/ 5%-95%(non-condensing)
    Operation Power220VAC(±10%)50±3Hz (Optional: 100VAC,110VAC,120VAC,200VAC)
    Power Consumption1.0KW (max), 0.3KW(working)
    Noise<58db
    Scanner Dimensions (L×W×H)2200mm x918mm x1442mm
    Gross Weight700kgs
    Packing Volume5.5 CBM
    X-ray Generator:
    Anode Voltage140kv
    Anode Power0.35 MA
    Generate angle80 degree upward
    BrandChinese Brand
    Generate directfrom bottom to top
    Cooling / Duty CycleOil Cooling /100
