    TIP System 0.22m/S 38AWG Airport X Ray Equipment With CE ISO FDA

    Ask Lasest Price
    Brand Name : Securina
    Model Number : SA6040
    Certification : FCC/CE
    Price : $4999 - $29999/set
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 800 Set/Sets per Month
    Delivery Time : 5-8 working days
    • Product Details
    • Company Profile

    TIP System 0.22m/S 38AWG Airport X Ray Equipment With CE ISO FDA

    TIP System Support Airport X-Ray Security Scanning Equipment With CE, ISO, FDA

    X-rays have the following main characteristics:


    1. Invisible to the naked eye, they penetrate opaque objects and bodies;
    2. The denser the absorption, the larger the ordinal (atom) number of the substance being studied in the atomic number table;
    Cause certain compounds and substances to emit light;
    3. Linear propagation (cannot bend around the object).


    Early X-ray security scanning equipment used to inspect luggage and cargo could only transmit black and white images, so now most models can use a wide range of color scanned images. Moreover, the projection of potentially dangerous or prohibited items and substances will have a specific color, which clearly reminds the operator that the object needs to be checked carefully. In addition, special color markings for organic materials are also provided.


    The X-ray security scanning equipment analyzes the X-ray radiation loss of different energy levels, so that the content of the inspection object can be divided into three groups. It implies the detection of organic, inorganic and intermediate substances. In terms of color, they are yellow, blue or green respectively. This effectively isolates potentially dangerous, undeclared and prohibited substances.


    SA6040 X-Ray Security Scanning Equipment Specifications:


    Tunnel Size600(W)*400(H)mm
    Conveyor Speed0.22m/s
    Conveyor Max Load170kg
    Dose per Inspection<2.9μ Gy/h
    Resolution<0.101mm Metal Wire
    Spatial resolutionLevel: Dia1.0mm, Vertical: Dia1.3mm
    Penetrate resolutionDia 0.511mm
    Penetration30-32mm steel
    Film SafetyGuarantee ISO1600 Film
    X-ray Leakage<0.5 μ Gy/h (at a distance of 5cm From external housing)
    Image System :
    Technical PrincipleDual-energy X-ray Imaging; L Shaped Array
    X-ray SensorL-Shaped Photodiode Array (multi-energetic)
    MonitorHigh Resolution Color, LCD Accord, 17inch
    Image DisplayHigh resolution of 1024 * 1280 pixel; Image Grey Level: 65536
    Image Enhancement1-64times enlargement continuity, Color/BW, negative, high/low
    penetration, organic /inorganic Stripping, general enhancement, and pseudo color, etc.
    Image Recall:All preceding images recallable, retrieval.
    Explosives & Narcotics DetectionExplosives & narcotics alarm and highlight according to atomic number signature
    High Density Region AlarmImpenetrable region alarm and highlight, for possible concealing of
    threats and contrabands
    Image ArchiveUp to 100,000 images stored automatically, enable transferring to USB disk, and
    converting to JPG, BMP and other general formats
    Miscellaneous FunctionsTime/date display, counters, user management, system-on/X-ray-on
    timers, power on self test, built-in diagnostic facilities, dual-direction scanning, system log, system standby and stimulant training,etc
    Network ApplicationsMultiple remote applications available based on Ethernet LAN and
    windows platform, such as image centralized storage and identify, recheck workstation, and network TIP, etc ( Optional) .
    Images process24bit real time processing ,4colors analysis, Images displayed marked date and ID NO ,Count the number of bags ,Memory gray level:65536
    Operating Environment:
    Operation temperature/Humidity0ºC-40ºC/10%-95%(non-condensing)
    Storage Temperature/Humidity-20ºCto 60ºC/ 5%-95%(non-condensing)
    Operation Power220VAC(±10%)50±3Hz (Optional: 100VAC,110VAC,120VAC,200VAC)
    Power Consumption1.0KW (max), 0.7KW(working)
    Noise<58db
    Scanner Dimensions (L×W×H)2007.5mm x868mm x1314 mm
    Gross Weight600kgs
    Packing Volume3.5 CBM
    X-ray Generator:
    Anode Voltage140kv
    Anode Power0.35 MA
    Generate angle80 degree upward
    BrandChinese Brand
    Generate directfrom bottom to top
    Cooling / Duty CycleOil Cooling /100

    Securina professional in manufacturing:


    1. Airport security screening equpiments and anti-terrorism protection equipment, namely: arched and hand-held metal detectors , baggage inspection introscopes and X-ray television systems , inspection mirrors , explosive and narcotic analyzer.

    2. Industrial metal detector, conveyor metal detetor, food metal detector, nail detector, needle detector for quality control in factory.
